I ROBOT PYRE firmware MT6572 scatter


Firmware info

MT6572 : MediaTek CPU EMMC
BaseBand CPU : MT6572, E01
SW_VER : MOLY.WR8.W1315.MD.WG.MP.V43
HW_VER : MPA701_CWET_KK_HSPA_HW
Android OS : KitKat

Firmware Situation :
Back-up by NCK tool as scatter file
Firmware already factory reset before backuping










Partitions count: 19


Partition: PRELOADER Start = 0x0              Len = 0x880000
Partition: MBR Start = 0x880000         Len = 0x80000
Partition: EBR1 Start = 0x900000         Len = 0x80000
Partition: PRO_INFO Start = 0x980000         Len = 0x300000
Partition: NVRAM Start = 0xc80000         Len = 0x500000
Partition: PROTECT_F Start = 0x1180000        Len = 0xa00000
Partition: PROTECT_S Start = 0x1b80000        Len = 0xa00000
Partition: SECCFG Start = 0x2580000        Len = 0x20000
Partition: UBOOT Start = 0x25a0000        Len = 0x60000
Partition: BOOTIMG Start = 0x2600000        Len = 0x600000
Partition: RECOVERY Start = 0x2c00000        Len = 0x600000
Partition: SEC_RO Start = 0x3200000        Len = 0x40000
Partition: MISC Start = 0x3240000        Len = 0x80000
Partition: LOGO Start = 0x32c0000        Len = 0x300000
Partition: EXPDB Start = 0x35c0000        Len = 0xa00000
Partition: ANDROID Start = 0x3fc0000        Len = 0x32000000
Partition: CACHE Start = 0x35fc0000       Len = 0xe200000
Partition: USRDATA Start = 0x441c0000       Len = 0xa1f40000
Partition: BMTPOOL Start = 0xffff00a8       Len = 0x1500000



Screenshot Fig. 2

A rare firmware Rom is shared FREE and 100% tested
Firmware is back-up by NCK Tool from Emerlits gsm service shop
Firmware Flash via Sp flash tool or gadget Box related MTK chips support
related free tools may be use is SP Flash Tool v5.1540 (MTK chips Flasher Tools) step by step procedure in Mobile tools




---------------------


I ROBOT PYRE firmware MT6572 scatter can use to same model about have problem about software related problem Hang, no power, password, pattern lock , anything about software related.
Best safe way is manual select flash the SYSTEM ANDROID file only.
Do it at your own risk, After flashing ! the device is set automatic in reset condition, All user data is lost.
Make sure back-up important data before to proceed flashing your phone.
Download : Link
passwordLink
DOWNLOAD NVRAM FIRMWARE
DOWNLOAD DRIVERS Extract the downloaded compress file using 7 ZIP or winrar and provide given password if asked, Do it at your own risk, After flashing ! the device is set automatic in reset condition, All your user data is lost. Make sure back-up first before to proceed flashing your phone.
