Cherry Mobile Amber W380 Firmware ROM




Cherry Mobile Amber W380 Firmware ROM was back-up Firmware by me by using NCK mediatek dongle via scatter file.
The information of scatter file ROM below shows

Android version : 4.4.2 Stock ROM
Baseband : MOLY.WR8.W1315.MD.MP.V1
Kernel : 3.4.5 Rooted
Model name : CM Amber W380

NCK mediatek Dongle Backup firmware Logs:


Reinsert phone battery.
 Battery must be charged.
 Phone must be off with battery inside.
 Please insert USB cable now...
 Detected : MediaTek PreLoader USB VCOM (Android) (COM3)
 Phone detected...Please wait
 Sending DA agent, please wait...
 BaseBand CPU :MT6572_S00
 BaseBand CPU Secure Version : FF
 BaseBand CPU Bootloader Version : 01
----------------------------------------------------
 INT RAM: 128 KB SDRAM
 EXT RAM: 512 MB  DRAM
----------------------------------------------------
 EMMC: (29Gb+4096Mb) SANDISK 0x53454d303447
 EMMC FW VERSION: 28:00:00:00:00:00:00:00
 EMMC CID: 45010053454D30 : 000000000000000000
 EMMC UA SIZE: 0xec000000
 BOOT STYLE: EMMC BOOT
 FULL LENGTH: 0xec600000       [3.693 GB]

 Detecting high speed port, wait......
 If driver not installed, install high speed port driver.
 If not need high speed port, disable it.
 After repeat opperation.
 Detecting high speed port, wait......
 Detected : MediaTek DA USB VCOM (Android) (COM6)
 Detected partitions count: 20
 Start dumping flash, this can take up to 1 hour.......
 Start procesing PRELOADER ......
 Start procesing MBR ......
 Reading:  BEGIN: 0x600000         - LEN: 0x200
 Start procesing EBR1 ......
 Reading:  BEGIN: 0x680000         - LEN: 0x200
 Start procesing PRO_INFO ......
 Reading:  BEGIN: 0x700000         - LEN: 0x300000
 Start procesing NVRAM ......
 Reading:  BEGIN: 0xa00000         - LEN: 0x500000
 Start procesing PROTECT_F ......
 Reading:  BEGIN: 0xf00000         - LEN: 0xa00000
 Start procesing PROTECT_S ......
 Reading:  BEGIN: 0x1900000        - LEN: 0xa00000
 Start procesing UBOOT ......
 Start procesing BOOTIMG ......
 Reading:  BEGIN: 0x2380000        - LEN: 0x600000
 Start procesing RECOVERY ......
 Reading:  BEGIN: 0x2980000        - LEN: 0x600000
 Start procesing SEC_RO ......
 Reading:  BEGIN: 0x2f80000        - LEN: 0x40000
 Start procesing LOGO ......
 Start procesing ANDROID ......
 Reading:  BEGIN: 0x3d40000        - LEN: 0x28a00000
-----------------------------------------------------------

A total file in folder 714 MB not compress.
Note : This Firmware is already used to flashback to same device and its 100% tested using said tools
As we see the backup information using NCK mediatek tool that what version phone about, device product and project.

We can use flash back this Firmware Rom via PC and tools that have scatter file support like sp flash tool, Must better use NCK tools which is back-up this ROM
If you don't have NCK, You can use SP flash tool read more step by step and download HERE

Be sure you read and understand the info backup Firmware and step by step before proceeding to program your device.


Firmware can use to same model about have problem about software related problem Hang, no power, password, pattern lock , infected by virus, anything about software related.
Best safe way is manual select flash the SYSTEM ANDROID file only.
Do it at your own risk, After flashing ! the device is set automatic in reset condition, All user data is lost.
Make sure back-up important data before to proceed flashing your phone.
